Informasjon
TY-CSP1
Imaging element
1/2.7"5MP CMOS
Field of view (H x V)
360 x 60
F number of the lens
2.5
Lens TTL
14.7 mm
Distortion
-14.90%
Microphone
MEMS Microphone array
Number of microphones
7
Beam forming
Supported
Microphone sensitivity
-35dBFS
S/N ratio
68.75 dBA
Speaker output
1.5 W (When supplying power from USB Type-C) or
3 W (When AC adaptor is connected)
Connection terminals
USB Type-C (Receptacle/USB2.0) DC plug 12 V/2 A
Power supply
USB Type-C (5 V/3 A) or AC adaptor DC 12 V/2 A
Power consumption (when outputting video)
11 W
Dimensions
?64 mm × 285 mm/?2.52" x 11.23"
(Operation base ?100 mm (?3.94"))
Mass
950 g/2.1 lbs.
Security slot
Noble Wedge lock(mounting ?11 mm or less)
Operating condition
Temperature: 0 °C to 40°C (32°F to 104°F)
Humidity: 20 % to 80 % (no condensation)
Usable altitude range
0 m to 2800 m (0 to 9186 ft)
