| Color | Black |
| Input Connections | Parallel Neutrik® NL4 |
| Speaker Type | Full-range |
| Frequency Response (-3 dB) | 65 - 20000 Hz |
| Frequency Response (-10 dB) | 45 - 20000 Hz |
| Internal Crossover | Yes |
| Recommended High-Pass Frequency | 45 Hz |
| Sensitivity 1 W/1 m | 100 dB |
| Max. SPL/1m (calc) | 133 dB |
| Coverage (Nominal -6 dB) H | 90 ° |
| Coverage (Nominal -6 dB) V | 50 ° |
| Rotatable Horn | No |
| System Power Handling (Continuous/Program/Peak) | 500 Watts |
| LF Transducer | SMX2151 |
| HF Transducer | DH3 |
| Crossover Frequency | 1750 Hz |
| Nominal Impedance (Passive) | 8 ? |
| Minimum Impedance | 6.2 ? |
| Enclosure Material | Plywood and MDF with EVCOAT |
| Flying | No |
| Height | 475 mm (18.7") |
| Width | 439 mm (17.28") |
| Depth | 655 mm (25.79") |
| Weight Net | 23.5 kg (51.81 lbs) |
